Page 85 - ZSi-Foster Product Catalog

General Fittings

Flat Plate Fittings “U” Shape Fittings
Pages 86 - 91
Pages 114 - 121

Wing Fittings
90° Angle Fittings Pages 122 - 126

Pages 92 - 101

Angle Fittings Post Bases
Pages 127 - 130
Pages 102 - 105

Trolley
Brace Fittings Pages 131 - 132

Pages 106 - 109

Conveyor Application
Fittings

Page 133

“Z” Fittings

Pages 110 - 113

Fittings Specifications Fitting Finish Specifications
ASTM Finish Description
Material ASTM
Description A dark green low gloss powder coating is applied and
Paint-Green Powder
A 575, A 1011, Coating thoroughly baked after steel has been cleaned and
Hot Rolled Plate A 1018, A 576, Steel, sheet and strip, carbon drawing phosphatized.
quality, special killed, hot rolled.
A638 Fittings and hardware supplied as "Electro-Galvanized" in
A 366, Steel carbon, cold rolled sheet, commer- Electroplated accordance with ASTM B 633.
Fitting: Steel
A 36 cial quality structural steel.
Strip Steel: A 569 Steel, sheet and strip, carbon drawing Mill-Galvanized Galvanized steel used in the manufacture of channel
sections conforms to ASTM A 653 GR33 G90. Uncoated
Pipe Clamps quality, special killed, hot rolled.
(Pre-Galvanized) edges resulted from slitting, punching and channel cut off
A 240 are present.
TYPE 304 Heat resisting chromium and
Stainless Steel chromium-nickel stainless steel plate, Channel and fittings which are hot dip galvanized after
A 240 sheet, strip for pressure vessel. Hot Dip Galvanized fabrication conform to one of the following specifications.
TYPE 316 After Fabrication ASTM A 123, ASTM A153, or ASTM A386.
Aluminum alloy extruded bar, rod, Other commercially available finishes can be supplied per
Aluminum B 221
wire, shape and tube. Special Coatings specification when required to
protect applications.
See page 25 for Material or Finish ordering codes for part numbers.
