Technical Data Gamma Pads Rooftop Supports Concrete Inserts Beta Clamps & Z-Clamps Loop & Ring Clamps Spring Steel Electrical Fittings Pipe & Conduit Supports General Fittings Channel Nuts & Hardware Channel IntroductionZSi-Foster Engineering Catalog – 237 –WARNING: These products can expose you to chemicals including lead, which is known to the State of California to cause cancer, and which is known to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.CBMPH SeriesSupport with Raised SPH Cush-A-Ring Clamp for Copper Tube or Steel Tube or PipeSee Page 194 for more information on the SPH Cush-A-Ring ClampsCush-A-Block® Mini Rooftop SupportsStandard Finish: Electro-Galvanized (EG)CBMPH Series Cush-A-Block Mini with Raised SPH Cush-A-Ring Clamp for Copper or Steel Tube or PipePart No. D IP CT Ring HeightUniform Load Lbs (kN) *CBMPH1 0.433\1⁄4\3⁄8\1.4\125(0.56 kN)CBMPH2 0.591\3⁄8\1⁄2\1.4\CBMPH3 0.787\1⁄2\3⁄4\1.6\CBMPH4 0.984\3⁄4\1\1.8\CBMPH5 1.22\1\11⁄4\2.0\CBMPH6 1.575\11⁄4\11⁄2\2.4\CBMPH7 1.89\11⁄2\- 2.6\CBMPH8 2.126\- 2\2.8\CBMPH9 2.244\2\- 3.1\CBMPH10 2.52\- 21⁄2\3.9\Below parts have 2 bolt configuration SPH ClampsCBMPH11 2.874\21⁄2\3\4.3\125(0.56 kN)CBMPH12 3.268\3\- 4.8\CBMPH13 3.937\- 4\5.3\CBMPH14 4.252\4\- 5.7\* This load is only for the capacity of the components in this assembly. Please consult roofing manufacturer or engineer for roof load capacity.4\102mm5\127mm8\203mm6-5⁄8\168mmWWW.ZSI-FOSTER.COMRingHeight3⁄8” Rod 10mmD
