Concrete Inserts

Standard Finish: Pre-Galvanized (PG)
Flared Wedge Concrete Inserts - 1 ⁄8" x 1 ⁄8" x 2 ⁄16" - 12 Gauge
5
11
7

2 ⁄16"
11
68mm

1 ⁄8"
7
48mm
1"
25mm
No hooks
5
1 ⁄8" No anchors
41mm No bending rebars
No problems

FLORIDA STRUT VERSABAR WESANCO Size
-- VC9004 -- 4" (102mm)
-- VC9006 -- 6" (152mm) Introducing the Versabar VC9000 Flared Wedge Insert
-- VC9009 -- 9" (229mm) The VC9000 inserts exceptional load-bearing capacity is not dependent
-- VC9012 -- 12" (305mm) upon pierced or welded anchor hooks of any kind. The elimination of sharp
-- VC9018 -- 18" (457mm) edged hooks and straps makes the handling and installation of the VC9000
7
-- VC9024 -- 24" (610mm) much safer, faster, and more economical. Its overall height is only 1- ⁄8".
-- VC9030 -- 30" (762mm) This low profile permits the VC9000 to be installed between reinforcing bars
-- VC9036 -- 36" (914mm) and forms, and other locations with shallow clearances. Its unique design
-- VC9042 -- 3' - 6" (1.1m) precludes the possibility of installers bending anchors to avoid obstructions,
thereby creating hidden load capacity reduction hazards of unknown
-- VC9048 -- 4' - 0" (1.2m) magnitude. The VC9000's solid back design eliminates concrete seepage
-- VC9054 -- 4' - 6" (1.4m) through spine openings and thereby avoids costly chipping needed to
-- VC9060 -- 5' - 0" (1.5m) remove hardened seepage.
-- VC9066 -- 5' - 6" (1.7m)
-- VC9072 -- 6' - 0" (1.8m) The VC9000 has a standard strut slot configuration, and accepts all
-- VC9078 -- 6' - 6" (2.0m) standard strut system related components. Connections can be made at
any point along the slot opening by using channel nuts, lateral locking nuts
-- VC9084 -- 7' - 0" (2.1m) or square nuts.
-- VC9090 -- 7' - 6" (2.3m)
-- VC9096 -- 8' - 0" (2.4m) Our flared wedge design causes the concrete to encase the VC9000 during
-- VC9102 -- 8' - 6" (2.6m) pouring, minimizing formation of air pockets. The flared wedge shape
-- VC9108 -- 9' - 0" (2.7m) locks the insert securely within the concrete and gives the VC9000 superior
-- VC9114 -- 9' - 6" (2.9m) loading capacity directly related to the concrete strength curve as described
-- VC9120 -- 10' - 0" (3.0m) on the next page. This exceptional strength characteristic is inherently with
modern concrete construction practices, and highly desirable in the pre-cast
-- VC9144 -- 12' - 0"(3.6m) and pre-stressed concrete fields.
-- VC9168 -- 14' - 0" (4.2m)
-- VC9192 -- 16' - 0" (4.8m)
-- VC9216 -- 18' - 0" (5.4m)
-- VC9240 -- 20' - 0" (6.1m)
-- VC9288 -- 24' - 0" (7.3m)

5
1
Hole Diameter: ⁄16" (14mm); Hole Spacing - From End: ⁄16" (21mm); Hole Spacing - On Center: 1- ⁄8" (48mm); Width: 1- ⁄8"(41mm); Thickness: ⁄4" (6mm)
9
13
7
– 284 – www.zsi-foster.com
