Page 81 - Demo

Technical Data Gamma Pads Rooftop Supports Concrete Inserts Beta Clamps & Z-Clamps Loop & Ring Clamps Spring Steel Electrical Fittings Pipe & Conduit Supports General Fittings Channel Nuts & Hardware Channel IntroductionZSi-Foster Engineering Catalog – 81 –WARNING: These products can expose you to chemicals including lead, which is known to the State of California to cause cancer, and which is known to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.Channel NutsStandard Finish: Electro Galvanized (EG)Channel Nut with Long SpringUse with W100 and W150Channel Nut with Standard SpringUse with W200, W210, and W300Channel Nut with Short SpringUse with W400, W500, W800, and W900Channel Nut Without SpringUse with W100, W150, W200, W210, W300, W400, W500, W800, and W900Part No. Size ThicknessW1-4 1⁄4\1⁄4\W1-6 3⁄8\3⁄8\W1-8 1⁄2\1⁄2\W1-10 5⁄8\7⁄16\W1-12 3⁄4\Part No. Size ThicknessW5-0832 #8 - 321⁄4\W5-1032 #10 - 32W5-1024 #10 - 24W5-4 1⁄4\W5-5 5⁄16\3⁄8\W5-6 3⁄8\W5-8 1⁄2\W5-10 5⁄8\Part No. Use Size ThicknessW1-10WS ccc 5⁄8\7⁄16\W2-0832WS #8 - 321⁄4\W2-1032WS #10 - 32W2-1024WS #10 - 24W2-4WS 1⁄4\W2-5WS 5⁄16\3 W2-6WS ⁄8\3⁄8\W2-7WS 7⁄16\W2-8WS cc 1⁄2\1⁄2\W2-10WS cc 5⁄8\7⁄16\W2-12WS cc 3⁄4\W5-8WS c 1⁄2\3⁄8\W5-10WS c 5⁄8\C = Use with W400 and W500CC = Not for Use with W400, W500, & W900CCC = Use with W100 and W150Part No. Size ThicknessW2-0832 #8 - 321⁄4\W2-1032 #10 - 32W2-1024 #10 - 24W2-4 1⁄4\W2-5 5⁄16\3 W2-6 ⁄8\3⁄8\W2-7 7⁄16\W2-8 1⁄2\1⁄2\W2-10 5⁄8\7 W2-12 ⁄16\3⁄4\W2-14 7⁄8\Mini Nut with Standard SpringUse with W600Mini Nut with Short SpringUse with W700Part No. Size ThicknessW7-0836 #8 - 360.150\(4mm)W7-0832 #8 - 32W7-1032 #10 - 32W7-1024 #10 - 24W7-4 1⁄4\Part No. Size ThicknessW6-0836 #8 - 360.150\(4mm)W6-0832 #8 - 32W6-1032 #10 - 32W6-1024 #10 - 24W6-4 1⁄4\Channel Nut With ConeUse with W100, W150, W200, W210, W300, W400, W500, W800 and W900Part No. Size ThicknessW2-4CN 1⁄4\1⁄4\W2-6CN 3⁄8\3⁄8\W2-8CN 1⁄2\1⁄2\Size
