Cush-A-Glide ™

Cush-a-Glide™

Cush-A-Glide is designed for fast installation of copper tube or pipe,
and can be easily installed in seconds with fasteners of your choice.
Just spread the clamp apart placing it over the top of a tube or
pipe and fasten one side. Push in the opposite side to the desired
tightness, allowing for expansion and contraction, then fasten the
other side.
• • Allows for expansion and contraction of copper tube and pipe
• • Excellent alternative to stainless or galvanized clamps
• • Fits tightly and securely against mounting surfaces Step 1: Spread open Cush-a-Glide, Step 2: Secure one side of
Cush-a-Glide with a
and place it over tube, pipe,
• • Made from trusted high quality TPE material or hose fastener of your choice
• • One piece molded split ring design
• • Suitable for indoor or outdoor applications Secure
• • Temperature range of -50°F to 275°F (-45°C to 135°C)
• • Will not rust and prevents and eliminates galvanic corrosion
• • Made in the USA

Step 3: Simply glide tube or pipe Step 4: Fasten second side of
through the Cush-a-Glide the Cush-a-Glide
to desired position
Glide to
Position
Secure

Pipe, Hose Dimensions – inches
Part No. or Tube Size T
Size A B L Thickness W
0.245" 1.000" 1.465"
1
A Size CAGB04 ⁄4" (6mm) (25mm) (37mm)
0.370" 0.500" 1.125" 1.590" 0.110" 0.375"
CAGB06 3 ⁄8"
(9mm) (13mm) (29mm) (40mm) (3mm) (10mm)
0.495" 1.250" 1.715"
T CAGB08 1 ⁄2" (13mm) (32mm) (44mm)
0.620" 1.500" 2.045"
CAGB10 5 ⁄8"
(16mm) 0.563" (38mm) (52mm) 0.150" 0.500"
0.870" (14mm) 1.750" 2.295" (4mm) (13mm)
CAGB14 7 ⁄8"
Ø Hole (22mm) (44mm) (58mm)
W 0.195" 1.120" 2.125" 2.730"
1
5mm CAGB18 1 ⁄8" (28mm) (54mm) (69mm)
(2 Ea.)
B CAGB20 1 ⁄4" 1.250" 2.250" 2.855" 0.625"
1
L (32mm) (57mm) (73mm) (16mm)
3
CAGB22 1 ⁄8" 1.370" 0.625" 2.375" 2.980" 0.180"
(35mm) (16mm) (60mm) (76mm) (5mm)
1.620" 2.625" 3.230"
5
CAGB26 1 ⁄8"
(41mm) (67mm) (82mm) 0.750"
2.120" 3.125" 3.730" (19mm)
1
CAGB34 2 ⁄8"
(54mm) (79mm) (95mm)
– 206 – www.zsi-foster.com
