Premier Cushioned Clamp

Tubing Sizes

Shoulder Bolt Introduction
Hole Size Height

Center to Channel
Top of Strut Clamp
Guides
Tubing O.D. Sizes
Tubing Copper Hole Center to Clamp
Part No. Width Height Improved Channel Nuts & Hardware
O.D. (Nom.) Size Top of Strut Guides Width Cushion
100025 1 ⁄4" - 0.250" 0.62" 0.22" 1.11" with Clamp
100031 5 ⁄16" - 0.313" 0.75" 0.28" 1.24" Guides
100037 3 ⁄8" 1 ⁄4" 0.375" 0.75" 0.28" 1.24"
100047 0.47" - 0.470" 0.87" 0.34" 1.36" General Fittings
100050 1 ⁄2" 3 ⁄8" 0.500" 0.87" 0.34 1.36"
100062 5 ⁄8" 1 ⁄2" 0.625" 1.00" 0.41 1.50"
100075 3 ⁄4" 5 ⁄8" 0.750" 1.33" 0.53" 1.78"
100087 7 ⁄8" 3 ⁄4" 0.870" 1.45" 0.58" 1.91"
100100 1" - 1.000" 1.66" 0.66" 2.03" Brackets
1
100112 1- ⁄8" 1" 1.125" 1.79" 0.72" 2.16"
100119 1.19" - 1.190" 1.92" 0.72" 2.30"
1
100125 1- ⁄4" - 1.250" 1.92" 0.78" 2.30"
1
3
100137 1- ⁄8" 1- ⁄4" 1.375" 2.22" 0.91" 2.75" Beam Clamps
1
100150 1- ⁄2" - 1.500" 2.22" 0.91" 2.75"
5
1
100162 1- ⁄8" 1- ⁄2" 1.625" 2.47" 1.03" 3.03"
3
100175 1- ⁄4" - 1.750" 2.47" 1.03" 3.03"
7
100187 1- ⁄8" - 1.900" 2.47" 1.16" 3.28"
100200 2" - 2.000" 2.72" 1.16" 3.28" Pipe & Conduit Supports
1
100212 2- ⁄8" 2" 2.125" 2.97" 1.28" 3.53"
1
100225 2- ⁄4" - 2.370" 3.22" 1.41" 3.78"
3
100237 2- ⁄8" - 2.370" 3.22" 1.41" 3.78"
1
100251 2- ⁄2" - 2.500" 3.47" 1.53" 4.03"
1
5
100262 2- ⁄8" 2- ⁄2" 2.625" 3.47" 1.53" 4.03"
7
100287 2- ⁄8" - 2.870" 3.73" 1.65" 4.28" Electrical Fittings
100300 3" - 3.000" 3.97" 1.78" 4.52"
1
100312 3- ⁄8" 3" 3.125" 3.97" 1.78" 4.52"
3
100337 3- ⁄8" - 3.375" 4.09" 1.89" 4.84"
5
1
100362 3- ⁄8" 3- ⁄2" 3.625" 4.47" 2.03" 5.03" Spring Steel
100400 4" - 4.000" 4.80" 2.28" 5.50"
1
100412 4- ⁄8" 4" 4.125" 5.09" 2.34" 5.66"
1
100425 4- ⁄4" - 4.250" 5.21" 2.40" 5.76"
5
100431 4- ⁄16" - 4.340" 5.27" 2.44" 5.85" Concrete Inserts
3
100437 4- ⁄8" - 4.375" 5.33" 2.47" 5.92"
5
100462 4- ⁄8" - 4.625" 5.59" 2.60" 6.17"
100492 4.92" - 4.920" 5.88" 2.74" 6.46"
100500 5" - 5.000" 6.25" 2.81" 6.75"
1
100512 5- ⁄8" 5" 5.125" 6.25" 2.81" 6.75" Rooftop Supports
100600 6" - 6.000" 7.50" 3.31" 7.75"
1
100612 6- ⁄8" 6" 6.125" 7.50" 3.31" 7.75"
5
100631 6- ⁄16" - 6.313" 7.71" 3.44" 8.06"
3
100637 6- ⁄8" - 6.375" 7.77" 3.47" 8.12" Technical Data
1
100650 6- ⁄2" - 6.500" 7.90" 3.53" 8.25"
Additional sizes available on request.
