Technical Data Gamma Pads Rooftop Supports Concrete Inserts Beta Clamps & Z-Clamps Loop & Ring Clamps Spring Steel Electrical Fittings Pipe & Conduit Supports General Fittings Channel Nuts & Hardware Channel IntroductionZSi-Foster Engineering Catalog – 195 –WARNING: These products can expose you to chemicals including lead, which is known to the State of California to cause cancer, and which is known to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.SPP Cush-A-Ring ClampsSPP Cush-A-Ring Clamp for PEX, CPVC, or PVC Pipe• With quick locking system• Clamp easy to close with one hand• Specially formulated, green, UV, and age resistant EPDM rubber lining• Perfect for PEX, Fusion, CPVC, and PVC pipe• ASTM E-84• Complies with MSS SP-58 and SP-69• Material steel, zinc platedThe Cush-A-Ring is a unique rubber lined hanger for PEX, CPVC, and PVC pipe. The SPP-1 thru SPP-10 has a two-part clamp with a hinged side and a single screw locking system. The quick locking system is easy to close with one hand, which makes it easier and faster for installation. The noise insulating rubber lining is made of UV-resistant EPDM rubber. The Cush-A-Ring is zinc plated for corrosion resistance.SPP-1 thru SPH-10SPP-11 thru SPH-14Part No.Dimensions (in)D IP CT B H h Rod SizeSPP-2 15 – 18 3⁄8\(10mm)1⁄2\(13mm)1.9\(48mm)1.4\(36mm)0.87\(22mm)3⁄8\(10mm)SPP-3 20 – 23 1⁄2\(13mm)3⁄4\(19mm)2.2\(56mm)1.7\(43mm)0.94\(24mm)SPP-4 25 – 28 3⁄4\(19mm)1\(25mm)2.4\(61mm)1.9\(48mm)1.0\(25mm)SPP-5 31 – 35 1\(25mm)1-1⁄4\(32mm)2.6\(66mm)2.2\(56mm)1.2\(30mm)SPP-6 40 – 43 1-1⁄4\(32mm)1-1⁄2\(38mm)3.0\(76mm)2.6\(66mm)1.3\(33mm)SPP-7 48 – 53 1-1⁄2\(38mm)- 3.3\(84mm)3.0\(76mm)1.5\(38mm)SPP-8 54 – 56 - 2\ (51mm)3.5\(89mm)3.0\(76mm)1.6\(41mm)SPP-9 60 – 65 2\ (51mm)- 4.3\(109mm)3.4\(86mm)1.7\(43mm)SPP-10 70 – 76 2-1⁄2\(64mm)- 4.9\(124mm)4.1\(104mm)2.2\(56mm)Below parts have 2 bolt configurationsSPP-11 86 – 91 3\(76mm)- 5.4\(137mm)4.6\(117mm)2.4\(61mm) 3⁄8\(10mm) SPP-12 110 – 114 4\(102mm)- 6.3\(160mm)5.8\(147mm)2.9\(74mm)SPP-13 124 – 132 - - 6.8\(173mm)5.9\(150mm)3.1\(79mm) 1⁄2\(13mm) SPP-14 155 – 160 - - 8.0\(203mm)7.4\(188mm)3.9\(99mm)SPP-1 thru SPP-9BDHhM6bsRod SizeSPP-10 thru SPP-14SPP Cush-A-Ring ClampsBHhM6bsD3⁄8” 10mm
