Beta Clamps - Standard

Standard Series Beta Clamps
• • Cushions are Polypropylene (Green Color)
• • Recommended for systems with less than 1,500 psi (103 bar) without dynamic loads. Introduction
• • Use for standard hydraulics, general pipe construction, electrical cables, and general
duty piping applications subject to moderate levels of shock and vibration.
• • Aluminum cushions are used in higher heat applications up to 500°F (260°C) Channel
INSTALLATION - Refer to technical data section for complete installation guide.

Part Tube Pipe Metric Dimensions
Group Bolt
No. * Size Size Size A2 H1 H2
S1004 1 ⁄4" (0.250) – –
S1006 3 ⁄8"(0.375 ) – – Channel Nuts & Hardware
SM1006 – – 6mm 1.34" 0.50" 1.13" 1 ⁄4"-20 x
S1 1
S1007 – 1 ⁄8" (0.405 ) – (34) (13) (29) 1 ⁄4"
Assembly Type “Z” SM1008 – – 8mm
- Strut Mounted SM1012 – – 12mm
S2008 1 ⁄2" (0.500 ) – – General Fittings
S2009 – 1 ⁄4" (0.540 ) –
Assembly Types S2010 5 ⁄8" (0.625) – – 1.57" 0.64" 1.42" 1 ⁄4"-20 x
S2 S2011 – 3 ⁄8" (0.675) – 1 ⁄8"
3
SM2014 – – 14mm (40) (16) (36) Brackets
SM2015 – – 15mm
SM2018 – – 18mm
S3012 3 ⁄4" (0.750) – –
S3014 – 1 ⁄2" (0.840) – Beam Clamps
S3015 7 ⁄8" (0.875) – – 1.96" 0.68" 1.49" 1 ⁄4"-20 x
S3 1
S3016 1" (1.000) – – (50) (17) (38) 1 ⁄2"
SM3020 – – 20mm
SM3025 – – 25mm
Z B S4017 – 3 ⁄4" (1.050) – 2.28" 0.82" 1.76" 1 ⁄4"-20 x Pipe & Conduit Supports
1
S4 S4018 1 ⁄8" (1.125) – – (58) (21) (45) 1 ⁄4"
3
SM4030 – – 30mm
1
S5020 1 ⁄4" (1.250) – –
S5021 – 1" (1.315) – 2.75" 1.13" 2.40" 1
1
0.12" 3mm S5 S5024 1 ⁄2" (1.500) – – ⁄4"-20 x
1
A2 Thick S5027 – 1 ⁄4" (1.660) – (70) (29) (61) 2 ⁄2" Electrical Fittings
1
SM5035 – – 35mm
3
S6028 1 ⁄4" (1.750) – – 1
1
S6 S6030 – 1 ⁄2" (1.900) – 3.38" 1.29" 2.71" ⁄4"-20 x Spring
3
2 ⁄4"
(33)
(86)
(69)
Size H2 S6032 2" (2.000) – – Steel
S7038 – 2" (2.375) –
S7036 2 ⁄4" (2.250) – –
1
1
S7 S7040 2 ⁄2" (2.500) – – 4.75" 1.88" 3.93" 1 ⁄4"-20
H1 3 (121) (48) (100) x 4" Concrete Inserts
S7044 2 ⁄4" (2.750) – –
S7048 3" (3.000) – –
*For additional sizes contact factory.
Note: Add assembly type to part number. Example: S1004S-SS provides the complete
1.2" assembly as shown with stainless steel components.
30mm NOTE: SM (metric) only available in Steel with Polypropylene (green) cushion. Rooftop Supports
SUFFIX
Components Cushion Example
none Steel Polypropylene (green) S1004S
Complete Beta Product Line - Refer to Foster -AL Steel Aluminum S1004S-AL
Quick Disconnects Product Catalog for more -SS Stainless Steel Polypropylene (green) S1004S-SS Technical Data
information on all available Beta Clamps
