Technical Data Gamma Pads Rooftop Supports Concrete Inserts Beta Clamps & Z-Clamps Loop & Ring Clamps Spring Steel Electrical Fittings Pipe & Conduit Supports General Fittings Channel Nuts & Hardware Channel IntroductionZSi-Foster Engineering Catalog – 219 –WARNING: These products can expose you to chemicals including lead, which is known to the State of California to cause cancer, and which is known to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.Anti-Vibration Split Rubber Bushings• Unique “grip” design secures cushion in place• High quality EPDM rubber provides superior vibration damping with excellent oil resistance.Z–Clamp - AdaptersPart No. Tube SizePipe Size A B C D EHAC-1 Series 11⁄2\G-1-4 1 ⁄4\– 0.235\0.975\(25 mm)0.875\(22 mm)0.50\(13 mm)1.312\(33 mm)G-1-6 3 ⁄8\– 0.360\G-1-8 1 ⁄2\– 0.485\G-1-10 5 ⁄8\– 0.610\G-1-12 3 ⁄4\– 0.735\HAC-2 Series 2\G-2-4 1 ⁄4\– 0.235\1.350\(34 mm)1.250\(32 mm)0.50\(13 mm)1.312\(33 mm)G-2-6 3 ⁄8\– 0.360\G-2-8 1 ⁄2\– 0.485\G-2-4P – 1 ⁄4\0.525\G-2-10 5 ⁄8\– 0.610\G-2-6P – 3 ⁄8\0.660\G-2-12 3 ⁄4\– 0.735\G-2-8P – 1 ⁄2\0.825\G-2-14 7⁄8\– 0.860\G-2-16 1\– 0.985\G-2-12P – 3 ⁄4\1.035\HAC-3 Series 3\G-3-4 1 ⁄4\– 0.234\2.287\(58 mm)2.187\(56 mm)0.750\(19 mm)1.750\(44 mm)G-3-6 3 ⁄8\– 0.360\G-3-8 1 ⁄2\– 0.485\G-3-4P – 1 ⁄4\0.525\G-3-10 5 ⁄8\– 0.610\G-3-6P – 3 ⁄8\0.660\G-3-12 3 ⁄4\– 0.735\G-3-8P – 1 ⁄2\0.825\G-3-14 7⁄8\– 0.860\G-3-16 1\– 0.985\G-3-12P – 3 ⁄4\1.035\G-3-20 1-1 ⁄4\1.235\G-3-16P – 1\1.300\G-3-24 1-1 ⁄2\– 1.485\G-3-20P – 1-1 ⁄4\1.645\G-3-24P – 1-1 ⁄2\1.885\G-3-32 2\– 1.985\C DEABFor use with Beta Adapters and Z-Clamps
