Technical Data Gamma Pads Rooftop Supports Concrete Inserts Beta Clamps & Z-Clamps Loop & Ring Clamps Spring Steel Electrical Fittings Pipe & Conduit Supports General Fittings Channel Nuts & Hardware Channel IntroductionZSi-Foster Engineering Catalog – 217 –WARNING: These products can expose you to chemicals including lead, which is known to the State of California to cause cancer, and which is known to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.O-Ring Face Seal• Offered in a wide range of sizes in JIC, NPT, SAE, and ORFS thread configurations.• Zinc plated to prevent corrosion• Clamping at the fitting prevents loosening and other vibration related leaksFor use with Beta Adapters and Z-ClampsZ–Clamp - AdaptersPart No. Tube SizeDimensions – inchesA B. C D E F. G I (Thread) HMJO-1-6 3 ⁄8\1.00\(25 mm)1.96\(50 mm)0.43\(11 mm)0.28\(7 mm)0.54\(14 mm)0.26\(7 mm)0.84\(21 mm) 11 ⁄16\ 0.496\(13 mm)MJO-1-8 1 ⁄2\1.00\(25 mm)2.10\(53 mm)0.50\(13 mm)0.28\(7 mm)0.54\(14 mm)0.38\(10 mm)0.84\(21 mm) 13 ⁄16\ 0.621\(16 mm)MJO-1-10 5 ⁄8\1.00\(25 mm)2.30\(58 mm)10.60\(15 mm)0.28\(7 mm)0.54\(14 mm)0.48\(12 mm)0.84\(21 mm) 1\-14 0.748\(19 mm)MJO-2-6 3 ⁄8\1.50\(38 mm)2.08\(53 mm)0.43\(11 mm)0.34\(9 mm)0.54\(14 mm)0.26\(7 mm)1.20\(31 mm) 11 ⁄16\ 0.496\(13mm)MJO-2-8 1 ⁄2\1.50\(38 mm)2.22\(56 mm)0.50\(13 mm)0.34\(9 mm)0.54\(14 mm)0.38\(10 mm)1.20\(31 mm) 13 ⁄16\ 0.621\(16 mm)MJO-2-10 5 ⁄8\1.50\(38 mm)2.42\(61 mm)0.60\(15 mm)0.34\(9 mm)0.54\(14 mm)0.48\(12 mm)1.20\(31 mm) 1\-14 0.748\(19 mm)MJO-2-12 3 ⁄4\1.50\(38 mm)2.52\(64 mm)0.65\(17 mm)0.34\(9 mm)0.54\(14 mm)0.61\(15 mm)1.20\(31 mm) 1-3 ⁄16\ 0.873\(22 mm)MJO-2-16 1\1.50\(38 mm)2.58\(66 mm)0.68\(17 mm)0.34\(9 mm)0.54\(14 mm)0.81\(21 mm)1.20\(31 mm) 1-7⁄16\ 1.058\(27 mm)MJO-3-20 1-1 ⁄4\2.25\(57 mm)2.98\(76 mm)0.68\(17 mm)0.437\(11 mm)0.75\(19 mm)1.02\(26 mm)2.12\(54 mm) 1-11 ⁄16\ 1.309\(33 mm)MJO-3-24 1-1 ⁄2\2.25\(57 mm)2.98\(78 mm)0.68\(17 mm)0.437\(11 mm)0.75\(19 mm)1.26\(32 mm)2.12\(54 mm) 2\-12 1.621\(41 mm)I IHC C D D EB Ref.FGA
