– 124 – www.zsi-foster.comWARNING: These products can expose you to chemicals including lead, which is known to the State of California to cause cancer, and which is known to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.Cush-A-Nator®Contact Factory for Additional SizesCush-A-Nator® Standard (CN)Pipe Part No. Pipe SizeDimensions (inches)Steel SS304 SS316 A B C DCN14P CN14PSS CN14PS6 1⁄ 2\0.840\1.29\0.58\1.82\CN17P CN17PSS CN17PS6 3⁄4\1.050\1.57\ (40mm) 0.70\2.08\CN21P CN21PSS CN21PS6 1\1.315\1.76\0.81\2.34\CN30P CN30PSS CN30PS6 11⁄ 2\1.900\2.32\1.09\2.86\CN38P CN38PSS CN38PS6 2\2.375\2.82\1.41\3.67\CN46P CN46PSS CN46PS6 21⁄ 2\2.875\3.32\1.66\4.17\CN56P CN56PSS CN56PS6 3\3.500\3.95\1.97\4.79\CN64P CN64PSS CN64PS6 31⁄ 2\4.000\4.45\2.28\5.11\CN72P CN72PSS CN72PS6 4\4.500\4.95\2.53\5.92\Cush-A-Nator® Standard (CN) has an operating range of -50°F to 275°F (-45°C to 135°C).Cush-A-Nator® Standard (CN)Tube Part No. O.D. Tube SizeDimensions (inches)Steel SS304 SS316 A B C DCN04 CN04SS CN04S6 1⁄4\0.25\0.62\0.27\0.98\CN06 CN06SS CN06S6 3⁄ 8\0.37\0.82\0.33\1.13\CN08 CN08SS CN08S6 1⁄ 2\0.50\0.94\0.40\1.34\CN10 CN10SS CN10S6 5⁄ 8\0.62\1.06\0.46\1.54\CN12 CN12SS CN12S6 3⁄4\0.75\1.20\0.52\1.68\CN14 CN14SS CN14S6 7⁄ 8\0.87\1.31\0.58\1.82\CN16 CN16SS CN16S6 1\1.00\1.44\0.65\1.95\CN18 CN18SS CN18S6 11⁄ 8\1.12\1.57\(40mm) 0.70\2.08\CN20 CN20SS CN20S6 11⁄4\1.25\1.70\0.77\2.21\CN32M CN32MSS CN32MS6 32mm 32mm 1.51\0.76\2.55\CN22 CN22SS CN22S6 13⁄ 8\1.37\1.82\0.83\2.34\CN24 CN24SS CN24S6 11⁄ 2\1.50\1.95\0.90\2.47\CN26 CN26SS CN26S6 15⁄ 8\1.62\2.07\0.96\2.60\CN28 CN28SS CN28S6 13⁄4\1.75\2.20\1.02\2.73\CN30 CN30SS CN30S6 17⁄ 8\1.87\2.32\1.09\2.86\CN32 CN32SS CN32S6 2\2.00\2.45\1.15\3.04\CN34 CN34SS CN34S6 21⁄ 8\2.12\2.57\1.27\3.23\CN36 CN36SS CN36S6 21⁄4\2.25\2.82\1.41\3.67\CN38 CN38SS CN38S6 23⁄ 8\2.37\2.82\1.41\3.67\CN40 CN40SS CN40S6 21⁄ 2\2.50\2.94\1.46\3.79\CN42 CN42SS CN42S6 25⁄ 8\2.62\3.07\1.53\3.92\CN46 CN46SS CN46S6 27⁄ 8\2.87\3.32\1.66\4.17\CN75M CN75MSS CN75MS6 75mm 75mm 3.37\1.69\4.68\CN48 CN48SS CN48S6 3\3.00\3.57\1.78\4.42\CN50 CN50SS CN50S6 31⁄ 8\3.12\3.57\1.78\4.42\CN56 CN56SS CN56S6 31⁄ 2\3.50\3.95\1.97\4.79\CN90M CN90MSS CN90MS6 90mm 90mm 3.86\1.94\5.23\CN64 CN64SS CN64S6 4\4.00\4.45\2.28\5.11\CN66 CN66SS CN66S6 41⁄ 8\4.12\4.57\2.34\5.54\CN110M CN110MSS CN110MS6 110mm 110mm 4.99\2.81\6.38\CN72 CN72SS CN72S6 41⁄ 2\4.50\4.95\2.53\5.92\CN125M CN125MSS CN125MS6 125mm 125mm 5.61\2.81\7.00\CN96 CH96SS CN96S6 6\6.00\6.62\3.31\7.63\CN160M CN160MSS CN160MS6 160mm 160mm 6.62\3.31\7.63\CBD A
